Appendix B – Parts list
PCB-mounted components
Qty
Description
4
22 pF ceramic capacitors
1
3.3 nF ceramic capacitor
1
10 nF ceramic capacitor
1
47 nF ceramic capacitor
1
82 nF ceramic capacitor
1
100 nF ceramic capacitor
16
330 Ω 5% 1/4W resistors
7
1 kΩ 5% 1/4W resistors
1
4.7 kΩ 5% 1/4W resistor
3
10 kΩ 5% 1/4W resistors
2
22 kΩ 5% 1/4W resistors
1
100 kΩ 5% 1/4W resistor
1
10 MΩ 5% 1/4W resistor
1
10 kΩ trimpot with thumbwheel (e.g. Bourns 3352T)
1
100 kΩ trimpot with thumbwheel (e.g. Bourns 3352T)
3
BC337 NPN transistors (or BC547 / BC548 or similar)
1
1N400x series rectifier diode
2
32768 Hz “watch” crystal (12.5 pF load capacitance)
1
4.00 MHz ceramic resonator with built-in capacitor
3
common-cathode 7-segment LED displays (10-pin DIP, e.g. Kingbright SC52-11SRWA)
1
NE555 timer (bipolar)
1
74HCU04N hex inverter (unbuffered)
9
5 mm LEDs (red, green or yellow: normal intensity, diffused)
2
CDS photocells (LDRs), 20-60 kΩ when illuminated
