Assembling Instruc�ons
STEP 1
Open the carton, please conrm the product
accessories is complete
Accessories details:
1. Handrail decorave covers 2pcs
2. Lock screw M8X60 4pcs
3 Lock screw M8X50 4pcs
3. Mul-purpose wrench 1pc
4. Lock nut M10X25 1pc
5. Spring locking pin 1pc
6. Magnet safety switch 1pc
7. 5 # Allen
ey 1pc
STEP 2
Connect the signal line and Insert the pillar which
have a signal line inside
into the right side base, and insert another pillar
into the le side base,
Then use M8X60 screw locking.
STEP 3
Screw into the spring pin
STEP 4
Use M12X25 lock screw x the handle frame
on the base.
