GPI MR 5-30 Series User Manual

7
SPECIFICATIONS
Gallon Models Litre Models
Unit of Measure U.S. Gallon Litre
Flow Range 5 to 30 GPM 19 to 114 LPM
Operating Temperature -20° F to 125° F -29° C to 52° C
Typical Accuracy ± 2% ± 2%
Type Nutating Disc Nutating Disc
Housing Material Aluminum Aluminum
Maximum Working Pressure 50 PSIG 3.4 bar
Inlet/Outlet Fitting Size 3/4"*, 1" or 1-1/2" 3/4"*, 1" or 1-1/2"
Threads NPT NPT or BSPP*
Maximum Batch Total 999.9 9999
Maximum Cumulative Total 9,999,999.9 99,999,999
Approximate Ship Weight 8.1 lbs. 3.7 kg
Maximum Dimensions: Width: 8.0 inches 20.3 cm
Height: 7.0 inches 17.8 cm
Depth: 6.0 inches 15.2 cm
* Not available on ENP model.
Note: Accuracy is factory calibrated using diesel fuel. Field Calibration is available on all models.
