System & Memory
To view Accumulative counter
To view Round up Accumulator.
1) Press CLEAR for 5 seconds, LCD screen will be Shown PC (Price
Counter)
2) Press L/P to switch between PC (Price Counter) and LC ( Liter Counter)
3) Press STOP to end.
To view Accumulator with decimal 0.01+/- .
1) Press “ · “ for 5 seconds, LCD screen will be Shown PC (Price
Counter)
2) Press L/P to switch between PC (Price Counter) and LC ( Liter Counter)
3) Press STOP to end.
To view last 100 Transaction Memory
1) Press STOP for 5 seconds, LCD screen will shown the last transaction record
2) Press 3/˄ to scroll up and 1/˅ to scroll down for screech record
3) Press STOP to end.
Model Number OGM-DPS-25 OGM-DPS-40
OGM-DPS-50
Inlet Size 25mm 40mm 50mm
Flowrate 20-120 lpm 25-250 lpm 30-300 lpm
One-time Count 9 digits
Accumulated Count 11 digits
Max.Working Pressure 3.4 Mpa 1.8 Mpa 1.8Mpa
Application Media kerosene, diesel, gasoline, Heavy Oil
Accuracy /Repeatability
0.5% ≤ 0.17% 0.5% ≤ 0.17% 0.5% ≤ 0.17%
Carton Dimension 81.5x38.5x17.5 cm 82.5x43x17.5 cm 44x24x24 cm
G.W/N.W 20.5kgs/17.5kgs 36.5kgs/31.5kgs 16.5kgs/14.5kgs
Owner’s Operation Manual
Technical detail
Power Supply 12v DC, 24v DC, 220v AC
Body Material
Aluminum
Oval Gear Rotor
Aluminum
O-ring Viton (Standard) -15°C minimum
Rotor Shaft Aluminum (Standard)
Bearing Type No Bearing
