GPI TM Series User Manual

7
SPECIFICATIONS
Inlet and Outlet:
Spigot (Pipe) End Models:
TM300/TM300-P 3 inch Schd. 80,
Spigot (Pipe)
TM400/TM400-P 4 inch Schd. 80,
Spigot (Pipe)
NPT Models:
TM300-N/TM300-N-P 3 inch NPT
TM400-N/TM400-N-P 4 inch NPT
ANSI Flange Models:
TM300-F/TM300-F-P 3 inch 150#
ANSI Flange
TM400-F/TM400-F-P 4 inch 150#
ANSI Flange
DIN Flange Models:
TM300-D/TM300-D-P 3 inch PN10/PN16
DIN Flange
TM400-D/TM400-D-P 4 inch PN10/PN16
DIN Flange
Design Type: Turbine
Wetted Components:
Housing: PVC
Journal Bearings: PEEK
Shaft: Stainless Steel
Rotor and Nose Cone: Acetal
Washers: Stainless Steel
Max. Working Pressure:
 TM300(AllModels):225PSIG@73°F
 TM400(AllModels):225PSIG@73°F
  (NonCE),135PSIG@73°F
(CE applications)
U.S. Measurement
Unit of Measure: Gallon
Flow Range:
3inch: 40-400GPM
(Linearity: ±3.0% of Reading)
 30-600GPM
(Accuracy: ±2.0% Full Scale)
4inch: 60-600GPM
(Linearity: ±3.0 of Reading)
 40-800GPM
(Accuracy ±2.0% Full Scale)
Accuracy with Computer:
± 3.0% of reading (Accuracy can be
improved with field calibration)
Operating Temperature: +32° to +140° F
(Do not allow fluid to freeze inside meter.)
Battery Life: 5 years
Storage Temperature: –40° to +158° F
Product Weight - lbs.:
*
Spigot ANSI DIN
(Pipe) NPT Flange Flange
3 inch: 2.4 3.9 5.8 6.5
4 inch: 3.7 6.1 9.2 8.8
Dimensions - Inches (L x H x W):
**
Spigot (Pipe): 3 inch: 11.5 x 5.34 x 3.5
4 inch: 13.5 x 6.34 x 4.5
NPT: 3 inch: 14.7 x 5.78 x 4.37
4 inch: 17.0 x 6.7 x 5.87
ANSI Flange:
3 inch: 12.0 x 7.5 x 7.5
4 inch: 14.0 x 9.0 x 9.0
DIN Flange:
3 inch: 12.0 x 8.0 x 8.0
4 inch: 14.0 x 8.5 x 8.5
* Add .3 lbs. for Conditioned Signal Module.
** Add 1.1 inches to height for Conditioned Signal
module.
Metric Measurement
Unit of Measure: Litre
Flow Range:
3 inch: 151-1514 LPM
(Linearity: ±3.0% of Reading)
113-2271 LPM
(Accuracy: ±2.0% Full Scale)
4 inch: 227-2271 LPM
(Linearity: ±3.0 of Reading)
151-3028 LPM
(Accuracy ±2.0% Full Scale)
Accuracy with Computer:
± 3.0% of reading (Accuracy can be
improved with field calibration)
Operating Temperature: 0° to +60° C
(Do not allow fluid to freeze inside meter.)
Battery Life: 5 years
Storage Temperature: –40° to +70° C
Product Weight - kgs:
*
Spigot ANSI DIN
(Pipe) NPT Flange Flange
3 inch: 1.09 1.77 2.63 2.95
4 inch: 1.68 2.77 4.17 3.99
