GPI TM050 Operation Guide

5
SERVICE
! ! ! CAUTION ! ! !
PARTS
Dimensions - inches (W x H x L):
1/2 inch 2 x 2.5 x 4.3
3/4 inch 2 x 2.7 x 5.3
1 inch 2 x 3 x 6
1-1/2 inch 2.3 x 3.6 x 7
2 inch 2.8 x 4.1 x 7.5
Metric Measurement
Unit of Measure: Litre
Flow Range:
1/2 inch 3.8 - 38 LPM
3/4 inch 7.6 - 76 LPM
1 inch 19 - 190 LPM
1-1/2 inch 38 - 380 LPM
2 inch 76 - 760 LPM
Accuracy: ± 3.0% (Accuracy can be
improved with field calibration)
Operating Temperature:
* 0° to +60° C
Storage Temperature: –40° to +70° C
Product Weight:
1/2 inch .141 kg
3/4 inch .173 kg
1 inch .232 kg
1-1/2 inch .368 kg
2 inch .518 kg
Dimensions - cm (W x H x L):
1/2 inch 5.1 x 6.4 x 10.9
3/4 inch 5.1 x 6.9 x 13.5
1 inch 5.1 x 7.6 x 15.2
1-1/2 inch 5.8 x 9.1 x 17.8
2 inch 7.1 x 10.4 x 19.1
* Do not allow fluid to freeze inside meter.
For warranty consideration, contact your local
distributor. If you need further assistance, con-
tact the GPI Customer Service Department at:
1-800-835-0113
You will need to:
•Provide information from the decal on your
meter.
• Receive a Return Authorization number.
•Flush any fluid from the meter before ship-
ping to the factory.
• If possible leave customer installed fittings
or ample length of bare pipe for reinstalla-
tion.
Do not return the meter without specific
authority from the GPI Customer Service
Department. Due to strict regulations gov-
erning transportation, handling, and disposal
of hazardous or flammable liquids, GPI will
not accept meters for rework unless they
are completely free of liquid residue.
The following replacement parts and acces-
sories are available for the TM Series meters:
Part No. Description
113520-1 Battery Replacement Kit
116001-1 Calibration Container, Large (5 gallon)
901002-52 O-Ring
125508-01 1/2 inch, Soc Turbine Assy Kit
125508-02 1/2 inch NPT, PVC Turbine Assy Kit
125510-01 3/4 inch, Soc Turbine Assy Kit
125510-02 3/4 inch NPT, PVC Turbine Assy Kit
125512-01 1 inch, Soc Turbine Assy Kit
125512-02 1 inch NPT, PVC Turbine Assy Kit
125514-01 1-1/2 inch, Soc Turbine Assy Kit
125514-02 1-1/2 inch NPT, PVC Turbine Assy Kit
125516-01 2 inch, Soc Turbine Assy Kit
125516-02 2 inch NPT, PVC Turbine Assy Kit
Computer Kits:
125509-01 1/2 inch, Computer Assy Kit
125511-01 3/4 inch, Computer Assy Kit
125513-01 1 inch, Computer Assy Kit
125515-01 1-1/2 inch, Computer Assy Kit
125517-01 2 inch, Computer Assy Kit
