GPI TM075 User Manual

7
U.S. Measurement
Unit of Measure: Gallon
Flow Range:
½ inch 1 - 10 GPM
¾ inch 2 - 20 GPM
1 inch 5 - 50 GPM
1 ½ inch 10 - 100 GPM
2 inch 20 - 200 GPM
Accuracy with Computer: ± 3.0% of read-
ing (Accuracy can be improved with field
calibration)
Operating Temperature: +32° to +140° F
(Do not allow fluid to freeze inside meter.)
Storage Temperature: –40° to +158° F
Product Weight:
*
Spigot (Pipe) NPT BSP
½ in. .38 lbs. .55 lbs. N/A
¾ in. .43 lbs. .67 lbs. N/A
1 in. .49 lbs. .84 lbs. .84 lbs.
1 ½ in. .66 lbs. 1.38 lbs. 1.47 lbs.
2 in. .78 lbs. 1.78 lbs. 1.93 lbs.
Dimensions - Inches (W x H x L):
**
Without Fitting With NPT Fitting
½" 2.1 x 2.5 x 4.3 2.1 x 2.7 x 6.0
¾" 2.1 x 2.7 x 4.4 2.1 x 2.9 x 6.1
1" 2.1 x 2.9 x 4.5 2.1 x 3.1 x 6.5
1 ½" 2.1 x 3.6 x 5.4 2.3 x 3.8 x 7.6
2" 2.4 x 4.1 x 5.5 3.5 x 4.4 x 7.9
With BSP Fitting
½" N/A
¾" N/A
1" 2.1 x 3.1 x 6.7
1 ½" 2.2 x 3.7 x 7.6
2" 2.7 x 4.2 x 7.8
* Weight with computer display. Conditioned signal
output module adds .30 lbs.
** Dimensions with computer display. Conditioned
signal output module adds 1.1 inch to height.
Metric Measurement
Unit of Measure: Litre
Flow Range:
½ inch 3.8 - 38 LPM
¾ inch 7.6 - 76 LPM
1 inch 19 - 190 LPM
1 ½ inch 38 - 380 LPM
2 inch 76 - 760 LPM
Accuracy with Computer: ± 3.0% of read-
ing (Accuracy can be improved with field
calibration)
Operating Temperature: 0° to +60° C
(Do not allow fluid to freeze inside meter.)
Storage Temperature: –40° to +70° C
Product Weight:
*
Spigot (Pipe) NPT BSP
½ inch .172 kg .249 kg N/A
¾ inch .195 kg .304 kg N/A
1 inch .222 kg .381 kg .381 kg
1 ½ inch .299 kg .626 kg .666 kg
2 inch .354 kg .807 kg .875 kg
Dimensions - cm (W x H x L):**
Without Fitting With NPT Fitting
½" 5.3 x 6.4 x 10.9 5.3 x 6.9 x 15.2
¾" 5.3 x 6.9 x 11.2 5.3 x 7.3 x 15.5
1" 5.3 x 7.4 x 10.9 5.3 x 7.9 x 16.5
1 ½" 5.3 x 9.1 x 13.7 5.8 x 9.7 x 19.3
2" 6.1 x 10.4 x 14.0 8.9 x 11.2 x 20.0
With BSP Fitting
½" N/A
¾" N/A
1" 5.3 x 7.9 x 17.0
1 ½" 5.6 x 9.4 x 19.3
2" 6.9 x 10.7 x 19.8
* Weight with computer display. Conditioned signal
output module adds .14 kg.
** Dimensions with computer display. Conditioned
signal output module adds 2.8 cm to height.
PARTS
The following replacement parts and acces-
sories are available for the TM Series meters:
Part No. Description
113435-1 Conditioned Signal Output Module
113520-1 Battery Replacement Kit
116000-1 Calibration Container, Large (5 gallon)
125508-03 ½ inch, Turbine Assy Kit
125508-04 ½ inch NPT, PVC Turbine Assy Kit
125510-03 ¾ inch, Turbine Assy Kit
125510-04 ¾ inch NPT, PVC Turbine Assy Kit
125512-03 1 inch, Turbine Assy Kit
125512-04 1 inch NPT, PVC Turbine Assy Kit
125514-03 1 ½ inch, Turbine Assy Kit
125514-04 1 ½ inch NPT, PVC Turbine Assy Kit
125516-03 2 inch, Turbine Assy Kit
125516-04 2 inch NPT, PVC Turbine Assy Kit
901002-52 Seal
125512-05 1 inch BSP, PVC Turbine Assy Kit
125514-05 1 ½ inch BSP, PVC Turbine Assy Kit
125516-05 2 inch BSP, PVC Turbine Assy Kit
Computer Kits:
125509-03 ½ inch, Computer Assy Kit
125511-03 ¾ inch, Computer Assy Kit
125513-03 1 inch, Computer Assy Kit
125515-03 1 ½ inch, Computer Assy Kit
125517-03 2 inch, Computer Assy Kit
