GR 0 Series - Parts List; Pump Model

ITEM
NO.
PART NAME PART
NUMBER
MAT’L
CODE
QTY ITEM
NO.
PART NAME PART
NUMBER
MAT’L
CODE
QTY
OM−02806
0 SERIES
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 04A13−(F3L) W/MANF
(From S/N 830179 Up)
> 1 PUMP CASING 4634E 13045 1
2 IMPELLER 3762ED 14000 1
3 SEAL ASSY 25271−207 −−− 1
> 4 STUD C0606−1/2 15991 5
5 SEAL PLATE GSKT 3768GA 19140 1
6 SEAL PLATE 38272−522 13040 1
> 7 STUD C0608 15991 3
> 8 STUD C0808 15991 12
9 LOCKWASHER J08 15991 12
10 HEX NUT D08 15991 12
11 STUD C0606−1/2 15991 8
12 LOCKWASHER J06 15991 8
13 HEX NUT D06 15991 8
14 HEX HD CAPSCREW B0604 15991 4
15 LOCKWASHER J06 15991 4
16 AIR VENT S1703 −−− 1
17 BEARING SHIM SET 8543 15990 1
18 HARDWARE KIT 48153−015 −−− 1
19 −MM 10X30 CAPSCREW 22645−164 −−− 12
20 −M10 LOCK WASHER 21171−511 −−− 12
21 −MM 10X65 CAPSCREW 22645−558 −−− 8
22 −M10 LOCK WASHER 21171−511 −−− 8
23 IMP ADJ SHIM SET 37J 17090 1
24 SHAFT SLEEVE 31414−074 16000 1
25 SPRING CTR WASHER 31512−024 17060 1
26 COUPLING W/O BUSHING 24391−101 −−− 1
27 −CONNECTION RING NOT AVAILABLE 1
28 −FLEX ELEMENT NOT AVAILABLE 1
29 −CLAMP RING NOT AVAILABLE 1
30 −SPACER NOT AVAILABLE 1
31 −HUB NOT AVAILABLE 1
32 −HEX HD CAPSCREW NOT AVAILABLE 3
33 −LOCKWASHER NOT AVAILABLE 3
34 −HEX HD CAPSCREW NOT AVAILABLE 6
35 −LOCKWASHER NOT AVAILABLE 6
36 SHAFT KEY N0609 15990 1
37 TAPER LOCK BUSHING 24131−115 −−− 1
38 OIL SEAL 25227−689 −−− 1
39 INTERMEDIATE BRKT 38263−609 10010 1
40 BALL BEARING S1080 −−− 1
41 SIGHT GAUGE 26714−011 −−− 1
42 PIPE PLUG P06 15079 1
43 PIPE PLUG P06 15079 1
44 BALL BEARING 23413−209 −−− 1
45 RETAINING RING S244 −−− 1
46 BRG CAP GSKT 38683−207 18000 1
47 BEARING CAP 38322−214 10010 1
48 OIL SEAL 25227−689 −−− 1
49 IMPELLER SHAFT 38514−546 15010 1
>50 WEAR RING 3765A 14000 1
>51 COVER PLATE GSKT 4635GA 20000 1
>52 STUD C0606−1/2 15991 4
>53 LOCKWASHER J06 15991 4
>54 HEX NUT D06 15991 4
>55 COVER PLATE 4635 13040 1
>56 STUD C0606−1/2 15991 8
57 NAME PLATE 38818−020 13990 1
58 DRIVE SCREW BM#04−03 17000 4
NOT SHOWN:
> 2" ADAPTOR 26531−455 −−− 1
DUST CAP 26531−088 −−− 1
LUBE DECAL 38816−079 −−− 1
DISCHARGE MANIFOLD 46441−003 −−− 1
SUCTION MANIFOLD 46441−004 −−− 1
DISCH MANIFOLD ASSY 46441−005 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
> INCLUDED IN REPAIR PUMP CASING ASSEMBLY, PART NUMBER 46471−241
