0 SERIES
OM−02806
PAGE I − 1INTRODUCTION
INTRODUCTION
Thank You for purchasing a Gorman-Rupp pump.
Read this manual carefully to learn how to safely
install and operate your pump. Failure to do so
could result in personal injury or damage to the
pump. This Installation, Operation, and Mainte-
nance manual is designed to help you achieve the
best performance and longest life from your Gor-
man-Rupp pump.
The pump end less engine is a Gorman-Rupp self-
priming centrifugal model 04A13-(F3L) W/MANF,
and is designed in accordance with MIL-P-52144D.
The model consists of an 0 Series pump end (Army
drawing No. 13220E1066) suction manifold (Army
drawing No. 13220E1072), discharge manifold
(Army drawing No. 13220E1074) and a 4-inch,
180_ flanged discharge connection (Army drawing
No. 13220E1076).
The pump is powered by a Deutz F3L diesel en-
gine. If there are any questions regarding the en-
gine, contact:
Deutz Corporation
7587 Ponce DeLeon Circle
Atlanta, Georgia 30340
The Type I pump and manifolds are designed to
deliver aircraft or vehicle fuels at a rate of 350 GPM
at a Total Discharge Head of 275 feet. The Type II
pump and manifolds are preserved during
manufacture to handle clean water at the same
performance level as the Type I pump. If the interior
of the Type II pump becomes contaminated with
fuel, do not use it again for pumping water. See
Section E, Page 1 for performance curves for both
Type I and Type II pumps.
When ordering repair parts, specify whether the
pump is a Type I or Type II. Tf only the pump end
requires replacement, specify Model 04A13-(F3L)
and the manifolds will not be provided. To obtain
repair parts for items not listed in this manual, con-
tact the prime contractor that supplied the end item
assembly.
If there are any questions regarding the pump or its
application which are not covered in this manual or
in other literature accompanying this unit, please
contact your Gorman-Rupp distributor, or:
The Gorman-Rupp Company
P.O. Box 1217
Mansfield, Ohio 44901−1217
Phone: (419) 755−1011
or:
Gorman-Rupp of Canada Limited
70 Burwell Road
St. Thomas, Ontario N5P 3R7
Phone: (519) 631−2870
For information or technical assistance on the en-
gine, contact the engine manufacturer’s local
dealer or representative.
The following are used to alert maintenance per-
sonnel to procedures which require special atten-
tion, to those which could damage equipment, and
to those which could be dangerous to personnel:
Immediate hazards which WILL result in se-
vere personal injury or death. These in-
structions describe the procedure required
and the injury which will result from failure
to follow the procedure.
Hazards or unsafe practices which COULD
result in severe personal injury or death.
These instructions describe the procedure
required and the injury which could result
from failure to follow the procedure.
Hazards or unsafe practices which COULD re-
sult in minor personal injury or product or
property damage. These instructions describe
the requirements and the possible damage
which could result from failure to follow the
procedure.
NOTE
Instructions to aid in installation, operation, and
maintenance or which clarify a procedure.
