SPECIFICATIONS
DEMOLITION
You have to operate the elimination of the materials in conformity with
the regulations in force. All materials must be divided by type (copper,
aluminium, plastic, electrical parts, etc)
DISMANTLING
In order to move away the automation, follow these instructions:
1 - cut off the power supply and disconnect the electrical installation;
2 - dismantle the control console and all the other components of the
installation.
If you have noticed that some components have been damaged, you
have to replace them.
USE OF THE AUTOMATION
Motor GR 100IL12_E GR 100IL220_E
Max. wing lenght 1,8 m 2,5 m
Max wing weight 200kg 250kg
Power supply 12 V 220/230 V
Motor capacity 48 W 350 W
Power absorbed 4,0 A 1,5 A
rpm 1600 900
Starting thrust 250 N/m 500 N/m
Working temp. -25°C +75°C -25°C +75°C
Weight 5,5 Kg 6 Kg
Opening time 10 sec. 12 sec.
Thermal prot. - 150ºC
Lubrication grease grease
Dimensions 380x180x155 380x180x155
Dimensioni of the plate 380x175x80 380x175x80
