Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
D This equipment is for professional use only.
D Read all instruction manuals, tags, and labels before operating the equipment.
D Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor.
D Do not alter or modify this equipment. Use only genuine Graco parts and accessories. Use only
extensions that are designed for use with your dispensing valve. Modifying parts can cause a
malfunction and result in serious bodily injury.
D Check equipment daily. Repair or replace worn or damaged parts immediately.
D Do not exceed the maximum working pressure of the lowest rated system component. The
tables on pages 8 and 9 give the maximum working pressures of the assemblies. The
maximum working pressure of your hose reel assembly is indicated on the hose reel identification
plate on the reel base. See also the Technical Data section on page 33.
D Use fluids and solvents that are compatible with the equipment wetted parts. Refer to the
Technical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s
warnings.
D Do not use hoses to pull equipment.
D Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not
expose hoses to temperatures above 82_C (180_F) or below –40_C (–40_F).
D Do not lift pressurized equipment.
D Comply with all applicable local, state, and national fire, electrical, and safety regulations.
D If you are adding a service hose and dispensing valve to a bare hose reel, be sure you know the
maximum working pressure of all the components.
D Never use a low-pressure flexible extension designed for low-pressure dispensing valves or
hand-powered lubricating equipment on a medium- or high-pressure dispensing valve.
