Graco Extend2Fit User Manual

81
6 Securing
Child
5. To Raise or Lower Headrest/
Harness Height
Squeeze the adjustment handle and move
headrest for the proper harness height.
6. Check the Buckle Position
The correct slot is the one that is closest
to your child without being underneath
them.
7. To Adjust Crotch Strap
Recline the car seat and locate the metal
retainer under the car seat shell.
8. Rotate Metal Retainer and Insert
It Up Through the Shell and Pad
From the top of the car seat, pull the
crotch buckle out.
9. Insert Metal Retainer in the New
Crotch Buckle Slot
Reach underneath the car seat and pull
the metal retainer through.

Graco Extend2Fit Specifications

General

Washing type	Machine wash
Certification	FMVSS 213
Product color	Multicolor
Car seat group	-
Adjustable headrest	Yes
Belt fastening type	5-point
Number of recline positions	6

Weight and Dimensions

Depth	640 mm
Width	487.7 mm
Height	561.34 mm
