Dimensions
36 307427ZAF
Dimensions
*Extends to 1614 mm (63.5 in.) overall; the pump length to 1180 mm (46.4 in.)
226943
226944
226945
226948
226952 (Shown)
237130
237131
237132
226940
226941
226942
226947
226953 (Shown)
237129
237133
237134
686445
BA 2” npt(m) Bung Adapter
Pump No.
A
Overall Length
B
Pump Length
C
Fluid Inlet
D
Fluid Outlet
226943, 226944, 226948, 237130, 237131 615 mm (34 in.) 181 mm (7.1 in.) 1-1/2 in. npt(f) 3/4 in. npt(f)
226945, 226952, 237132 685 mm (27 in.) 250 mm (9.8 in.) 1-1/2 in. npt(f) 3/4 in. npt(f)
226940, 226941, 226942, 226947, 226953,
237129, 237133, 237134, 686445
1315 mm (51.7 in.) 880 mm (34.6 in.) 1-1/2 in. npt(f) 3/4 in. npt(f)
226951 1158 mm (45.6 in.) 724 mm* (28.5 in.) Suction Tube 3/4 in. npt(f)
BA
