Installation
Installing the Hoses and Valves
NOTE: Use thread sealant on all male threads except
at the swivel unions.
1. Remove the plug from the top of the elevator cap,
and screw it into the air inlet (E) in the elevator
base. Screw the restrictor valve assembly (42) into
the elevator cap.
2. Screw the 1/4 x 1/8 npt adapter (85) into the
restrictor valve. Install the 1/4 x 3/8 npt adapter
(89). Connect one end of the 36 in.
(914 mm) hose into the adapter and the other hose
end into the snap-over valve’s (27) union (82).
Route the hose inside the arms of the pump
support (64) as shown in Fig. 3.
3. Screw the hex nipple (115 or 99) from the outlet
hose kit (91 or 97) to the pump outlet. Connect the
kit’s swivel union (96) to the adapterwith the
opening in the valve (94) facing down. Refer to the
Hose Kit parts drawing on page 18.
4. Install a bleed-type master air valve on the pump’s
air supply line. See the Typical Installation on
page 7.
WARNING
The bleed-type master air valve is required in your
system to relieve air trapped between this valve
and the pump after the air is shut off. Trapped air
can cause the pump to cycle unexpectedly and
cause serious injury, including splashing in the
eyes or on the skin. Position the valve close to the
pump.
5. Install a fluid shutoff valve on the fluid supply line
to shut off fluid to the pump.
6. Finish assembling the hoses and fittings as shown
in Fig. 3 and the Parts Drawing on
page 16.
