Assembling the booster seat
To adjust armrests, remove screw and press in button on side of base as
shown to raise or lower. Reinsert screw and tighten. CHECK to make
sure armrests are securely attached by pulling up on them.
Slip armrest covers (on certain models) onto armrests as shown.
Your Graco booster seat is now ready to use. See “Securing Child in
Vehicle with Shoulder Belt Positioning Clip”.
FOR MODELS with a back support continue on to
5
.
Flip head support and lower back support over as shown.
Squeeze red adjustment button and slide two pieces together until they
snap into place.
CHECK to make sure two pieces are securely snapped together by pulling
on them.
Attach elastic strap as shown.
Flip seat over and insert the fabric from the head support underneath the
fabric on the lower back support as shown.
To make insertion of fabric easier, slide the upper and lower back pieces
apart by squeezing the red adjustment button.
Attach backrest to base. “U”-shaped hooks on bottom of backrest will
interlock with bars on base.
Make sure that no part of the seat covering interferes when attaching
backrest to the base.
Once backrest is securely attached to the base, push backrest up as shown.
Your Graco booster seat is now ready to use. See “Using your Graco
Booster Seat” and “Securing Your Child in Vehicle”.
