Graco MARK V Instructions And Parts List

2 309277
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts, Pump
244197 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
244224 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
244201 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
244409 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
245902 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
245904 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
244954 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
244957 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
245889 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
287946 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
246257 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
287815 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
287814 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
248736 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
248971 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
277068 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
 This equipment is for professional use only.
 Read all instruction manuals, tags, and labels before operating the equipment.
 Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
 Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
 Do not exceed the maximum working pressure of the lowest rated system component. Refer to the
Technical Data on page 15 for the maximum working pressure of this equipment.
 Use fluids and solvents compatible with the equipment wetted parts. Refer to the Technical Data
section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
 Do not use 1,1,1–trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or
fluids containing such solvents in pressurized aluminum equipment. Such use could result in a
chemical reaction, with the possibility of explosion.
 Comply with all applicable local, state, and national fire, electrical, and safety regulations.
MOVING PARTS HAZARD
Moving parts can pinch or amputate your fingers.
 Keep clear of all moving parts when starting or operating the pump.
 Before servicing the equipment, follow the Pressure Relief Procedure on page 3 to prevent the
equipment from starting unexpectedly.
