Technical Data
30 311348C
Technical Data
Basic Sprayer Wetted Parts...............................
zinc- and nickel-plated carbon steel, nylon, stainless
steel, PTFE, Acetel, leather, UHMWPE, aluminum,
tungsten carbide, PEEK, brass
Noise Level
Sound power ...............................................91 dBa*
Sound pressure ..........................................82 dBa*
*per ISO 3744; measured at 3.1 feet (1 m)
Dimensions
Model
100 -
120V, A,
Hz
220 -
240V, A,
Hz
Generator
Minimum
W
Motor
HP (W)
Cycles
per gallon
(liter)
Maximum
Delivery
gpm (lpm)
Maximum Tip
Size
Fluid
Outlet
npsm
1
Gun
2
Guns
695
14,
50/60
9,
50/60
5000 1.75
(1300)
243
(64)
0.75
(2.8)
0.027 N/A 1/4 in
795
15,
50/60
10,
50/60
5000 2.00
(1490)
195
(52)
0.95
(3.6)
0.031 0.021 1/4 in
1095
15,
50/60
10,
50/60
5000 2.20
(1640)
123
(33)
1.1
(4.1)
0.033 0.023 1/4 in
Mark V
N/A 10,
50/60
5000 2.20
(1640)
110
(29)
1.2
(4.3)
0.035 0.023 3/8 in
1595
20/15,
50/60
N/A 5000 2.5
(1860)
110
(29)
1.25
(4.7)
0.037 0.025 1/4 in
Mark V
20/15,
50/60
N/A 5000 2.5
(1860)
110
(29)
1.25
(4.7)
0.037 0.025 3/8 in
Model
Weight lb (kg) Height in (cm)
Length
in (cm)
Width
in (cm)Lo-Boy Hi-Boy Lo-Boy Hi-Boy
695 94
(43)
94
(43)
26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25.75
(65.4)
20.5
(52.1)
795 98
(45)
98
(45)
26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25
(63.5)
20.5
(52.1)
1095 N/A 120
(55)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
1595 N/A 125
(57)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
Mark V N/A 130
(59)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
