Graco MARK V User Manual

Technical Specifications
3A6342A 79
795 Sprayers
U.S. Metric
Sprayer
Maximum Delivery 1.1 gpm 4.2 lpm
Maximum Tip Size 0.033 0.033
Fluid Outlet npsm 1/4 in. 1/4 in.
Cycles 195 per gallon 52 per liter
Generator Minimum 5000 W 5000 W
120V, A, Hz 15, 50/60
230V, A, Hz 10, 50/60
Dimensions
Weight:
Standard Series Lo-Boy 98 lb 45 kg
Standard Series Hi-Boy 98 lb 45 kg
ProContractor Series 115 lb 52 kg
Height:
Standard Series Lo-Boy 27.5 in. 69.9 cm
Standard Series Hi-Boy
28.5 in. (Handle down)
38.75 in. (Handle up)
72.4 cm (Handle down)
98.4 cm (Handle up)
ProContractor Series 39 in. 99 cm
Length:
Standard Series Lo-Boy 37 in. 94 cm
Standard Series Hi-Boy 26 in. 66 cm
ProContractor Series 29.5 in. 75 cm
Width: 22.5 in. 57.2 cm
Wetted parts
zinc- and nickel-plated carbon steel, nylon,
stainless steel, PTFE, Acetal, leather, UHMWPE,
aluminum, tungsten carbide, PEEK, brass
Noise Level:
Sound Power 91 dBa* 91 dBa*
Sound Pressure 82 dBa* 82 dBa*
*per ISO 3744;
measured at 3.1 ft
*per ISO 3744;
measured at 1 m
