Graco Mark X Operation Manual

Technical Data
38 332916E
1095 Sprayers
U.S. Metric
Sprayer
Maximum Delivery
North American Models 1.2 gpm 4.5 lpm
International Models 1.1 gpm 4.1 lpm
Maximum Tip Size 0.035 0.035
Fluid Outlet npsm 1/4 in. 1/4 in.
Cycles 123 per gallon 33 per liter
Generator Minimum 5000 W 5000 W
120V, A, Hz 15, 50/60 15, 50/60
230V, A, Hz 10, 50/60 10, 50/60
Dimensions
Weight:
Standard Series Hi-Boy 120 lb 55 kg
ProContractor 141 lb 64 kg
IronMan 127 lb 58 kg
Height:
Standard Series Hi-Boy
29.5 in. (Handle down)
38.5 in. (Handle up)
74.9 cm (Handle down)
97.8 cm (Handle up)
ProContractor 39 in. 99 cm
IronMan 40.2 in. 102 cm
Length:
Standard Series Hi-Boy 26 in. 66 cm
ProContractor 28 in. 71 cm
IronMan 29.9 in. 76 cm
Width:
Standard Series Hi-Boy 24 in. 61 cm
ProContractor 24 in. 61 cm
IronMan 24.4 in. 62 cm
Wetted parts
zinc- and nickel-plated carbon steel, nylon, stainless steel, PTFE, Acetal,
leather, UHMWPE, aluminum, tungsten carbide, PEEK, brass
Noise Level:
Sound Power 91 dBa* 91 dBa*
Sound Pressure 82 dBa* 82 dBa*
*per ISO 3744; measured at 3.1 ft *per ISO 3744; measured at 1 m
