Technical Data
42 332916E
Mark VII Sprayers
U.S. Metric
Sprayer
Maximum Delivery 1.58 gpm 6.0 lpm
Maximum Tip Size 0.041 in. 0.041 in.
Fluid Outlet npsm 1/2 in. 1/2 in.
Cycles 97 per gallon 26 per liter
Generator Minimum 5000 W 5000 W
230V, A, Hz 16, 50/60 16, 50/60
Dimensions
Weight:
Standard Series Hi-Boy 139 lb 63 kg
ProContractor 160 lb 73 kg
Height:
Standard Series Hi-Boy
29.5 in. (Handle down)
38.5 in. (Handle up)
74.9 cm (Handle down)
97.8 cm (Handle up)
ProContractor 39 in. 99 cm
Length:
Standard Series Hi-Boy 26 in. 66 cm
ProContractor 28 in. 71 cm
Width: 24 in. 61 cm
Wetted parts
zinc- and nickel-plated carbon steel, nylon, stainless steel, PTFE, Acetal,
leather, UHMWPE, aluminum, tungsten carbide, PEEK, brass
Noise Level:
Sound Power 91 dBa* 91 dBa*
Sound Pressure 82 dBa* 82 dBa*
*per ISO 3744; measured at 3.1 ft *per ISO 3744; measured at 1 m
