308026 13
Operation
06539B
T
U
X
KEY
A Pump
B Ram
C Wiper Plate
G Pump Air Bleed Valve
(required, for pump)
H Pump Air Regulator
T Ram Air Regulator
U Ram Director Valve
V Red-Handled Main Air Bleed Valve
(required, for pump and ram)
X Air Release Valve
JJ Pump Bleeder Valve
KK Wiper Plate Vent Handle
LL Vent Hole
A
B
C
H
G
KK
LL
JJ (not in view)
Fig. 4
V
