28 308026
Technical Data
Part No. Pump Model
Displacement
Pump Model Ratio
Maximum Fluid
Working
Pressure
Maximum
Pump Air Input
Pressure
Maximum
Package Air
Input Pressure
231113 Monarkr 222790
Check-Mate 450
10:1 124 bar, 12 MPa
(1800 psi)
12 bar, 1.2 MPa
(180 psi)
12 bar, 1.2 MPa
(180 psi)
231111
233028
Presidentr 237206
Check-Mate 450
20:1 248 bar, 25 MPa
(3600 psi)
12 bar, 1.2 MPa
(180 psi)
12 bar, 1.2 MPa
(180 psi)
231112 Senatorr 222790
Check-Mate 450
34:1 281 bar, 28 MPa
(4080 psi)
8 bar, 0.8 MPa
(120 psi)
10 bar, 1.0 MPa
(150 psi)
231166 Quiet Senatorr 222790
Check-Mate 450
34:1 281 bar, 28 MPa
(4080 psi)
8 bar, 0.8 MPa
(120 psi)
10 bar, 1.0 MPa
(150 psi)
231115
233029
Bulldogr 237450
Check-Mate 450
55:1 341 bar, 34 MPa
(4950 psi)
6.2 bar, 0.6 MPa
(90 psi)
10 bar, 1.0 MPa
(150 psi)
231167 Quiet Bulldogr 222790
Check-Mate 450
55:1 341 bar, 34 MPa
(4950 psi)
6.2 bar, 0.6 MPa
(90 psi)
10 bar, 1.0 MPa
(150 psi)
231117
234953
Monarkr 222771
Check-Mate 200
23:1 285 bar, 29 MPa
(4140 psi)
12 bar, 1.2 MPa
(180 psi)
12 bar, 1.2 MPa
(180 psi)
231118
234954
233030
Presidentr 237202
Check-Mate 200
46:1 317 bar, 32 MPa
(4600 psi)
7 bar, 0.7 MPa
(100 psi)
10 bar, 1.0 MPa
(150 psi)
Wetted parts
For wetted parts information, refer to your separate component manuals.
