13 14
Weight Guidelines
Rear-Facing with 5- Point Harness
0-9 kg MUST be rear-facing.
9-18 kg CAN be rear-facing.
Using 3-point belt only
Forward- Facing with 5- Point Harness
9-13 kg and can sit upright unassisted CAN be forward-facing.
13-18 kg SHOULD be forward-facing with harness.
Installation using ISOcatch System and 3-point belt or using
3-point belt only
Booster Mode with Vehicle Lap/Shoulder Seat Belt
15-18 kg CAN be in booster mode.
Over 18 kg MUST be in booster mode.
Installation using ISOcatch System and 3-point belt or
using 3-point belt only
For Installation with 3-point-belt
1. This is a ‘Universal’ child restraint. It is approved to UN ECE
regulation 44, 04 series of amendments, for general use in
vehicles and it will fit most, but not all, child restraint systems.
2. A correct fit is likely if the vehicle manufacturer has declared
in the vehicle handbook that the vehicle is capable of
accepting a ‘Universal’ child restraint for this age group.
3. This child restraint has been classied as ‘Universal’ under more
stringent conditions than those which applied to earlier
designs which do not carry this notice.
4. If in doubt, consult either the child restraint manufacturer or
the retailer.
For Installation with ISOcatch System
and 3-point-belt
1. This is a ‘Semi-Universal’ child restraint. It is approved to UN
ECE regulation 44, 04 series of amendments for general use in
vehicles fitted with ISOFIX anchorages systems.
2. It will fit vehicles with positions approved as ISOFIX positions
(as detailed in the vehicle handbook), depending on the
category of the child restraint and of the fixture.
3. If in doubt, consult either the child restraint manufacturer or
vehicle manufacturer.
Rear-Facing Seat :
Group 0+ /1 (0-18 kg)
Child restraint system must be rear-facing in the vehicle seat.
Make sure vehicle seat belt is routed through the rear-facing
belt path marked with a blue label.
Install this child restraint system tightly in your vehicle.
Harness straps must be at or just below the top of child’s
shoulders.
Infants who weigh less than 9 kg MUST be rear-facing.
Install Rear-Facing With Vehicle Seat Belt
Recline the child restraint system-
Place the child restraint system in recline position 1 or 2.
Place child restraint system Rear-Facing in the Vehicle-
Place the base flat on the vehicle seat. Push it back until the
front of the child restraint system touches the vehicle seat
back.
Route the Vehicle Seat Belt-
A
Unsnap the pad from back and pull lower seat pad forward to
expose the plastic shell.
B
Thread vehicle lap seat belt through the rear-facing belt path
(marked with a blue label) and buckle it. The seat belt should
lay as flat as possible and not be twisted. Make sure buckle
and seat belt are in line with each other. Contact Graco if in
doubt about this point. Replace the seat pad.
Thread the shoulder belt through the rear-facing shoulder
belt guide on the back of the seat marked with blue labels.
The seat belt should lay as flat as possible and not be twisted.
Tighten the Vehicle Seat Belt-
Press down firmly in the center of the child restraint system.
Pull on the shoulder belt to tighten while feeding the slack
back in the retractor.
Forward-Facing Seat:
Group 1 (9-18 kg)
Installation using ISOcatch System and 3-point belt or using
3-point belt only
Child restraint system must be forward-facing in the vehicle
seat.
Make sure vehicle seat belt is routed through the forward-
facing belt path marked with a bright red label.
Install this child restraint system tightly in your vehicle.
Harness straps must be at or just above the child’s shoulders.
Install Forward-Facing With
ISOcatch System
If vehicle is equipped with ISOFIX, the vehicle lower
anchor points may be visible at the vehicle seat crease. See
your vehicle owner’s manual for exact locations, anchor
identification, and requirements for use.
Fit the ISOcatch guides with the ISOFIX anchor points. The
ISOcatch guides can protect the surface of the vehicle
seat from being torn. They can also guide the ISOcatch
connectors.
Press the ISOcatch adjusting button to pull out the ISOcatch
connectors.
Rotate the ISOcatch connectors by 180 degrees until they are
pointing in the direction of the ISOcatch guides.
To Next Page
