14
Concerns on Installation
DO NOT install this enhanced child
restraint on vehicle seats that face
sideways or rearward with respect to
the moving direction of the vehicle.
It is recommended to install this
enhanced child restraint on the rear
vehicle seat.
DO NOT install this enhanced child
restraint on vehicle seats movable
during installation.
DO NOT place rear-facing enhanced
child restraint on front seat with air
bag, because death or serious injury
may occur. Please reference vehicle
owner’ s manual for more informa-
tion.
This infant carrier is suitable for
vehicle seats with i-Size ISOFIX
anchor points with the Base.
Handle Adjustment
To adjust the handle, squeeze the
handle buttons on both sides to
release it , and then rotate the handle
until it clicks into any of the 4
positions.
The handle of the infant carrier
module can be adjusted to 4
positions.
Position A Position for car, hand or
stroller transportation.
Position B&C Rocking position.
Position D Baby chair position.
Installation with base
Fit the ISOFIX guides with the ISOFIX
anchor points.
The ISOFIX guides can protect the
surface of the vehicle seat from being
torn. They can also guide the ISOFIX
connectors.
Unfold the load leg from storage
compartment.
Line up the ISOFIX connectors with
the ISOFIX guides, and then click
both ISOFIX connectors into the
ISOFIX anchor points.
Make sure that both ISOFIX
connectors are securely attached to
their ISOFIX anchor points. There
should be two audible clicks and the
colors of the indicators on the both
ISOFIX connectors should be
completely green.
Check to make sure the base is
securely installed by pulling on the
both ISOFIX connectors.
After placing the base on the vehicle
seat, extend the load leg to oor,
When the load leg indicator shows
green means it is installed correctly,
red means it is installed incorrectly.
1
2
3
4
5
6
7
8
9
