15
When the load leg indicator shows
red this means the load leg is in the
wrong position.
Make sure the load leg is in full
contact with the vehicle oor pan.
Squeeze the load leg releasing
button, then shorten the load leg
upwards.
The completely assembled base is
shown as
This infant carrier is suitable for
vehicle seats with i-Size ISOFIX
anchor points with the Base.
The ISOFIX connectors must be
attached and locked onto the ISOFIX
anchor points.
The load leg must be installed
correctly with green indicator.
Push the infant carrier down into the
base, if the enhanced child restraint
is secure, the enhanced child
restraint indicator shows green.
Pull up on the infant carrier to be
sure it is securely latched into the
base.
Press the ISOFIX
adjustment button
and push the base back against the
vehicle seat until tight.
To release the infant carrier, pull the
infant carrier up while pull out the
stroller x release button.
To remove the base, press the
secondary lock button rst and then
the ISOFIX releasing button on the
ISOFIX connectors before removing
the base from the vehicle seat.
Securing Child in the Enhanced
Child Restraint
While pressing the harness
adjustment button, pull completely
the two shoulder harnesses of the
enhanced child restraint.
Unlock the buckle of the harnesses
by pressing the red button.
Please do not remove the Head
Support before the baby sitting.
Infant insert is for children's
protection. Children whose height is
under 60cm are suitable to use the
infant insert.
Check that Shoulder Harness Straps
are set at the proper height.
Place child into the infant carrier-
module and lock the buckle.
Tighten the shoulder harnesses by
pulling adjustment webbing.
