Important
1
Important
1
15
Use the tether strap when
using forward-facing (A)
When used properly, the tether
helps reduce injury in a sudden
stop or crash.
Review section 5
Car Seat Does Not Move More
than 1” (2.5 cm) at the Belt
Path (B)
Review section 5
Harness Straps at or Just
Above Child’s Shoulders (C)
Review section 6
Chest Clip Even With Armpits (D)
Review section 6
Cannot Pinch Harness Straps
at the Shoulder (E)
Review section 6
Forward-Facing Installation
B
A
D E
C
NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 15NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 15 9/18/20 11:50 AM9/18/20 11:50 AM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco True3Fit LX and is the answer not in the manual?

Graco True3Fit LX Specifications

General IconGeneral
CategoryConvertible Car Seat
BrandGraco
ModelTrue3Fit LX
Weight Capacity5 - 65 lbs
Rear-Facing Weight Limit5-40 lbs
Forward-Facing Weight Limit22-65 lbs
Height CapacityUp to 49 inches
Forward-Facing Height LimitUp to 49 inches
Warranty1 Year Limited Warranty
Harness Type5-Point Harness
