Forward-Facing
with LATCH
5-C
61
5-C Install Forward-Facing with LATCH
1. Remove Lower Anchor Attachment from
Storage Location
Lift seat pad and remove lower anchor
connectors from storage location. First, push
on the tab on the seat in front of the lower
anchor connector (A) and then pull on the
lower anchor strap to remove the lower anchor
connector (B). Repeat on the other side.
2. Make Sure Lower Anchor Strap is in the
Forward-Facing Belt Path Marked with
Orange Label
To move the lower anchor strap, review
section 8.
A
B
Review your vehicle’s owner manual for LATCH location and use. Do not install
by this method for a child weighing more than 45 lb (20 kg).
Visit www.gracobaby.com
and the Graco
®
True3Fit™
LX car seat product page
to view installation videos.
NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 61NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 61 9/18/20 11:50 AM9/18/20 11:50 AM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco True3Fit LX and is the answer not in the manual?

Graco True3Fit LX Specifications

General IconGeneral
CategoryConvertible Car Seat
BrandGraco
ModelTrue3Fit LX
Weight Capacity5 - 65 lbs
Rear-Facing Weight Limit5-40 lbs
Forward-Facing Weight Limit22-65 lbs
Height CapacityUp to 49 inches
Forward-Facing Height LimitUp to 49 inches
Warranty1 Year Limited Warranty
Harness Type5-Point Harness
