Graco TURBOBOOSTER LX User Manual

38
4 Securing
Child
Using Belt Positioning Clip
1. Make Sure Vehicle’s Seat Shoulder Belt Lays in
the Red Zone As Shown
If the vehicle’s seat shoulder belt lays outside this zone,
you MUST use the belt positioning clip.
2. Attach Belt Positioning Clip
The shoulder belt positioning clip MUST be attached to
the slot on the bottom of the base. Insert the loop end
of strap through the slot on
bottom of seat exactly where
shown.
3. Push Clip and Strap Through Loop
Pass the clip and the strap through the loop end as shown
and pull strap up.

Graco TURBOBOOSTER LX Specifications

General

Headrest	No
Cup holder	Yes
Product type	No-back car booster seat
Washing type	Machine wash
Certification	FMVSS 213
Product color	Multicolor
Maximum weight	45.36 kg
Minimum weight	18.14 kg
Number of cup holders	1
