INSTRUCTIONS-P
ARTS LIST
307–785
Rev F
Supersedes E
120 VAC, 15 AMP
ULTRA 1000
AIRLESS P
AINT SPRA
YER
3000
psi (210 bar) MAXIMUM WORKING PRESSURE
Model 231–034, Series C
Basic
sprayer on Upright cart without
hose or gun
Model 231–043
Complete
sprayer on Upright cart with hose,
gun, RAC IV
, DripLess
T
ip Guard
and SwitchT
ip
U.S. P
A
TENT NO. 4,323,741, 4,397,610
PA
TENTED 1983, CANADA
AND OTHER P
A
TENTS PENDING
GRACO INC. P.O. BOX 1441
MINNEAPOLIS, MN
55440–1441
COPYRIGHT
1989, GRACO INC.
This
manual contains
IMPORTANT
INSTRUCTIONS and WARNINGS.
READ AND RETAIN FOR REFERENCE.
MODEL
231–043
Hazard of Using Fluids Containing Halogenated Hydrocarbons
Never
use 1,1, 1–trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids containing
such
solvents in this equipment. Such use could result in a serious chemical reaction, with the possibility of explo
-
sion,
which could cause death, serious bodily injury and/or substantial property damage.
Consult your fluid suppliers to ensure that the fluids being used are compatible with aluminum and zinc parts.
Refer to the T
echnical Data on page 44 for more information.
WARNING

Other manuals for Graco Ultra 1000

Preview: Instructions-Parts List
Instructions-Parts List44 pages

Questions and Answers

  • A
    adamdayAug 12, 2025
    What to do if my Graco Paint Sprayer motor won't operate?
    • D
      Derek MooreAug 12, 2025
      If the motor of your Graco Paint Sprayer doesn't operate, there are several things you can check: * Ensure the pressure control knob isn't at the minimum setting. Try slowly increasing the pressure. * Inspect the sprayer circuit breaker button (309) to ensure it hasn't popped up. Depress the button to reset it. * Examine the electrical supply with a voltmeter. It should read 105–125 VAC. Reset the building circuit breaker or replace the fuse, and try another outlet. * Check the power supply cord (311) and extension cord for any visible damage and replace if necessary.
  • S
    Samantha SmithAug 19, 2025
    Why won't my Graco Ultra 1000 Paint Sprayer motor start?
    • M
      Marcus PierceSep 12, 2025
      The Graco Paint Sprayer motor might not start due to several reasons: 1. The pressure control knob may be at the minimum setting. Increase the pressure setting slowly. 2. There might be frozen or hardened paint in the pump (76) or pressure control tube. Try to thaw it by plugging in the sprayer, turning it on, and slowly increasing the pressure. See NOTE 1 if this doesn't work. 3. The displacement pump connecting rod pin (43) might not be correctly placed. Push the pin into place and secure it with the spring retainer (42).
  • G
    Gregory WallaceAug 27, 2025
    How to troubleshoot a Graco Ultra 1000 that won't turn on?
    • M
      Melissa AveryAug 27, 2025
      To troubleshoot a Graco Paint Sprayer that won't turn on: * First, check the pressure control knob and increase the pressure setting slowly. * Next, check the sprayer circuit breaker (309) and reset it if necessary. * Also, verify the electrical supply using a voltmeter, ensuring it reads between 105–125 VAC. Reset the building circuit breaker or try another outlet. * Inspect the motor brush leads, terminals, and brush length. Tighten terminal screws or replace brushes if needed; brush length should be 1/2” minimum.
  • K
    Kevin EvansSep 3, 2025
    What to do if the Graco Paint Sprayer motor is damaged?
    • J
      Jack CarterSep 3, 2025
      If you suspect motor damage in your Graco Paint Sprayer, remove the drive housing assembly (67). If the fan won’t turn, replace the motor (73).

Graco Ultra 1000 Specifications

General IconGeneral
Max Pressure3000 PSI
Power SourceElectric
Hose Length50 ft
Spray PatternAdjustable
