Graco XP35 User Manual

Models
3A0420ZAF 13
XP50-h with Viscount II Hydraulic Motor, Series C
NOTE: All models are at Series C.
Models
Pump
Package
Volume
Mix Ratio
Specifications Includes Approval
284102 284202 284252 284302 284402
1.0 : 1 2.0 : 1 2.5 : 1 3.0 : 1 4.0 : 1
Max Fluid Working Pressure
psi (MPa, bar)
Maximum Hydraulic Oil Working
Pressure psi (MPa, bar)
Pressure Ratio
(Fluid to Air)
7 Gallon Hopper
Solvent Pump
HP Hazardous Location
Heaters, 240V
XTR504 Spray Gun
35 ft. (10.7m) Fluid Hose
Ex Marked HP
284104
X
X
4700
(32.4, 324)
1800
(12.4, 124)
2.6 : 1 X
XX
284204
X X
5050 (34.8,
348)
1800
(12.4, 124)
2.8 : 1 X
XX
284254
X X
5000
(34.4, 344)
1650
(11.3, 113)
3.0 : 1 X
XX
284304
X X
4700
(32.4, 324)
1800
(12.4, 124)
2.6 : 1 X
XX
284404
X X
5000
(34.4, 344)
1800
(12.4, 124)
2.8 : 1 X
XX
284105
X
X
4700
(32.4, 324)
1800
(12.4, 124)
2.6 : 1 X X X X X
284205
X X
5050 (34.8,
348)
1800
(12.4, 124)
2.8 : 1 X X X X X
284255
X X
5000
(34.4, 344)
1650
(11.3, 113)
3.0 : 1 X X X X X
284305
X X
4700
(32.4, 324)
1800
(12.4, 124)
2.6 : 1 X X X X X
284405
X X
5000
(34.4, 344)
1800
(12.4, 124)
2.8 : 1 X X X X X
