Graco XP35 - Page 61

Parts
3A0420ZAF 61
XP50 Systems
Ref. Part Description
Quantity
xxxxx1 xxxxx2 xxxxx3 xxxxx4 xxxxx5 xxxxx6 xxxxx7 xxxxx8 xxxxx9
1 26C338 CART, XP 111111111
2 262476 HUB, axle 1 1 1 1 11111
3 118841 Washer, flat, 5/8 2 2 2 2 22222
4 --- PUMP assembly See page 78, for detail
5 100133 Washer, lock, 3/8 in. 5 5 5 5 55555
6 100101 SCREW, 3/8-16 x 1in. 4 4 4 4 44444
7 113362 WHEEL, semi-pneumatic 2 2 2 2 22222
8 154628 WASHER 2 2 2 2 22222
9 113436 RING, retaining 2 2 2 2 22222
10 124410 BEARING, sleeve 1 1 1 1 11111
11 124664 WASHER, 1 in. 2 2 2 2 22222
12 262477 AXLE 1 1 1 1 11111
13 191824 WASHER, spacer 4 4 4 4 44444
14 113807 WHEEL, flat free 2 2 2 2 22222
15 258982 HANDLE, cart 1 1 1 1 11111
16 101242 RING, retaining 2 2 2 2 22222
17 26C417 MODULE, air controls (see page 69 for details) 111111111
18 100131 Nut, hex, 3/8-16 1 1 1 1 11111
19 25E211 LABEL, XP operation 1 1 1 1 11111
20 248927 KIT, mixer element (25 pack) 3 3 3 3 33333
21 111218 CAP, tube, square 4 4 4 4 44444
22 158491 FITTING, nipple 4 4 6 6 66666
23 15M987 FITTING, elbow, 60 224444444
24 H75003 HOSE, 7250 psi 222222222
25 H53825 HOSE,5000 psi, 3/8 in. x 25 ft 111111111
26 15B729 COUPLING 111111111
27 262478 HOUSING, mixer 3 3 3 3 33333
29 150287 COUPLING, pipe, 1/4 X 3/8 1 1 1 1 11111
30 H52510 HOSE, 5000 psi, 1/4 in. x 10 ft 111111111
31 XTR502 GUN, XTR5 111111111
32 162024 COUPLING 2 2 2 2 22222
35 262783 MANIFOLD, recirculation, XP50 (see page 70 for details) 1 1 1 1 11111
36 262807 MIX MANIFOLD (see page 70 for details) 1 1 1 1 11111
37 106212 SCREW, manifold mounting 2 2 2 2 22222
38 116139 GRIP, handle 2 2 2 2 22222
41 158683 FITTING 2 2 4 4 44444
47 206995 FLUID,TSL, 1 quart 1 1 1 1 11111
48 101566 NUT, lock 2 2 2 2 22222
49 15U654 LABEL, identification, A/B 1 1 1 1 11111
50 555357 SCREW, 1/4-20 x 0.5 in. 4 4 4 4 44444
51 124450 CLAMP, spring
2 222222
52 124293 BOLT, u-bolt 1 1 1 1 11111
53 124259 BRAKE, plunger clamp 1 1 1 1 11111
54 124291 PIN, spring 2 2 2 2 22222
55 24E872 BRACKET, hopper
2 222222
