23
7 PLAYBACKIN
These two RCA phono sockets are unbalanced Left and Right line-level inputs,
used for connecting a recording device.
8 PLAYBACKTOMIX
Press this switch to route the Playback in signals, connected to the Left and Right
RCA sockets 7, to the MIX Left/Right signal at the MIX outputs.
9 MONITORPLAYBACK
Press this switch to route the Playback signal to the monitor and phones, over-
riding the default Monitor/Phones signal.
0 MONITORLEVEL
This control sets the level to the MONITOR LEFT & RIGHT outputs. If headphones
are plugged into the PHONES jack, the headphone level will track the Monitor
Level.
q MONITOROUTPUTS
The Monitor Outputs are on 3-pole A gauge jacks and are balanced connections
w PHONESLEVEL
This control sets the output level to the Headphone outputs. If headphones are
plugged into the PHONES jack, then the knob sets a comfortable headphone
listening level without affecting the Monitor output levels.
e HEADPHONESJACK
The PHONES output is a 3-pole A gauge jack, wired as a stereo output as
shown, ideally for headphones of 200W or greater. 8W headphones are not
recommended.
r AUXOUTPUTS(1&2)
These outputs are on 3-pole A gauge jacks and are balanced outputs.
t AUXPRE/POSTSWITCHES
These two switches globally switch the AUX 1 and AUX 2 feeds, respectively, on
all the input modules to be either pre-fade or post-fade.
