GRADEN GS04 User Manual

1. Specifications
Model Graden GS04 Verticutter/Scarifier
Engine
Honda GX390
Power
13hp Horizontal shaft
Engine Oil
1.1 litres SAE 30W Grade
Fuel
Unleaded 86 RON (minimum)
Transmission Oil
SAE 30W Grade
Cutting Width
400mm
Cutting Depth
0-45mm (maximum with standard blades)
Blades
Tungsten carbide tipped spring steel
Blade Size
Part Number 0048
Part Number 0381
Part Number 0049
190mm Diameter – 2mm tip (Standard)
190mm Diameter – 1mm tip (Optional)
190mm Diameter - 3mm tip (Optional)
Blade Tip Speed
2150m/min at 3600 rpm
Weight
165 kg
Width
840mm
Tyres
15 x 6.00 / 6
Tyre Pressure
95 kPa (14 psi)
Rotor Belts
AP40 Gates Predator V-Belt
Gearbox Drive Belt
A27 Gates V-Belt
Transmission Drive Belt
A29 Gates V-Belt
