. INSTALLATION CONDITIONS
Graf UK Ltd

Coverage heights with telescopic dome shaft in green
areas.
Maximum coverage heights with extensions and
telescopic dome shaft.
Covering heights with cast telescopic dome shaft (with
class B cast cover) in areas with car trac (load up to
3.5 t).
Coverage heights with vehicle loading cover (suitable
cover to be provided by others) in areas used by trucks
with a max. weight of 12 t.
Coverage heights on installation in groundwater the
hatched area specifies the permissible immersion
depth for the tanks.
The immersion depth is 350 mm.
2
INSTALLATION CONDITIONS
1200
Mini telescopic
dome shaft
Maxi telescopic with cast iron lid
>800<1200
max 12 to
>800<1200
>800<1200
max.
350mm
