Side (A) – 1.0” Back (B) – 3.0” Vent – 0” Corner (E) – 3” Floor – 0”
FREE STANDING INSTALLATIONS
Your Grain Comfort Plus is designed for connection to the 3” diameter exhaust pipe, Stainless
Steel inlet box and Stainless Steel Wall Flange which is intended to exit straight out the back of
the unit and through an outside wall. Variations to a “Straight Out” installation can be made. A
Corner installation can be accomplished by incorporating 45 degree 6” pipe and a 45 degree 3”
exhaust bend. Variations on the installations are list here in this manual.
THROUGH WALL VENT INSTALLATION
EXHAUST and VENT MEASUREMENTS
MEASURE: (looking at the front of the stove)
13.5” from floor to hole (with legs on)
16.5” from the right hand side to the center of the hole
1- Cut a slightly oversized hole for the 6” Stainless Steel Wall Flange.
2- Test Fit the Flange Unit noting that it will slide apart to accommodate different wall
thicknesses. Check to make sure the assembly fits snugly.
3- Attach the 5” to 6” Galvanized Adapter to the 5” pipe protruding from the back of the
stove.
4- Visualize or test the placement of the stove. If acceptable, apply a bead of High
Temperature Silicone to the inside face of the Wall Flange and secure with wood screws.
