Service Detail – Terminal Block Element
Fig. 2
4) TEFLON INSULATOR
SEAL BAR
PRESSURE SPRING
TERMINAL SCREW
TERMINAL WIRE
BRASS WASHERS (2)
2) TERMINAL BLOCK
SET−SCREW
1) TERMINAL BLOCK
3) HEATING ELEMENT
(NICHROME)
