Step # 3, Connect the machine to electric power and compressed air.
Now that the components have been installed onto the rear panel you are ready to plug the machine
into an adequate power source and to connect it to a compressed air supply. If your machine was
ordered with the 220 VAC option then there will be no plug supplied as there are many types of 220
VAC connections. In regards to the compressed air supply it is very important that the machine be
supplied with
clean & dry air. You can also plug the footswitch into the outlet on the rear panel at
this time (refer to page 5).
The number shown around all three dials are for reference purposes and do not represent seconds
or any other time interval. The higher the number the dial points to the longer that function will be
engaged. The toggle switch shown on the control panel will let the PLC know whether you want gas
or vacuum to be the first operation to take place.
Important note: If you want to vacuum only with
no gas flush then set this switch to the Gas / Vac setting for best results.
4
