Grammer MSG 90.6PG - Page 205

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.21 Cable for electro-pneumatic gearshift (EPS) – removal and installation
Page 6 of 6
REMOVAL / INSTALLATION TABLE OF CONTENTS
12 For seat models Atego, Axor:
12.1 Remove the plug of the EPS cable
at the pin contact strip (see
Chapter 3.40).
12.2 Mark the points where the EPS
cable (1) is fastened or bundled by
means of three cable tie (11) and
remove the cable tie (11).
13 Pull the EPS cable (1) out of the
seat suspension in backward
direction and remove it.
14 Re-install the components in the
reverse order of their removal.
1
9
8
7
1
1
2
4
6
6
4
2
3
3
1
1
11
10
1111
2211
