Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.25 Operator console and armrest for electro-pneumatic gearshift (EPS) –
removal and installation (delivery option)
Page 1 of 5
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Support for EPS console
(2) Stud
(3) EPS control element
(4) Operator console for electro-
pneumatic gearshift = EPS console
(5) Cover (EPS console)
(6) Plug (EPS cable)
(7) Cable tie
(8) Micro-encapsulated cap
screw, M8 ........... to replace, 25 Nm
(9) Micro-encapsulated cap
screw, M8 ........... to replace, 25 Nm
(10) Micro-encapsulated cap
screw, M6 ........... to replace, 12 Nm
(11) Rounded head screw
(inner race) ............. to hand-tighten
13
15
12
14
5
3
4
16
16
15
17
2
1
20
9
6
7
11
11
11
11
8
19
18
2223
10
21
3
20
6
8
4
5
1
3
13
12
10
9
19
