Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.36 Air spring – removal and installation
Page 4 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
3 Hang out the Bowden pull wire for
seat height adjustment at the level
control (control disc) (see
Chapter 3.9).
4 Remove the cable for vehicle
connection at the level control
(see Chapter 3.20).
5 Remove the air hose for lumbar
support and lateral support adjustment
at the retainer of the level control (see
Chapter 3.22).
6 Remove the level control at the
swinging structure and lift off the level
control in upward direction as far as
possible (see Chapter 3.28).
Note:
The air hoses at the level control do
not need to be removed.
6
11
8
1
9
4
11
2
3
11
4
1
5
1
7
6
8
4
Z
10
