Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.36 Air spring – removal and installation
Page 5 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
7 For seat model Actros:
Remove the pin contact strip at the
supporting structure (see
Chapter 3.39).
Removal and installation
8 WARNING Risk of crushing!
Bring the seat into the highest position
and secure the swinging structure to
the front plastic rollers of the lower
suspension part by means of
appropriate spacers.
6
11
8
1
9
4
11
2
3
11
4
1
5
1
7
6
8
4
Z
10
