Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.40.3 Seat fore/aft adjustment – removal and installation (bus seat)
Page 1 of 3
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Lever for seat fore/aft adjustment
(2) Locking rail ...................... to grease
(3) Adjusting rail
(4) Seat fore/aft adjustment
= (2) + (3)
(5) Micro-encapsulated cap
screw .................. to replace, 25 Nm
(6) Hexagon nut
(7) Rotary table
(8) Swivel, upper part
(9) Swivel
= (7) + (8)
1 Remove the supporting structure
(Chapter 3.39).
F
F
6
6
5
5
3
6
6
7
7
3
2
2
4
4
1
1
4
9
5
3
8
45°
5
5
