Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.44 Seat suspension – removal and installation
Page 3 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
7 Hang out the Bowden pull wire for
quick lowering of the seat at the level
control (valve lever and retainer) (see
Chapter 3.7) and pull it out in
backward direction.
8 Remove the Bowden pull wire for seat
height adjustment at the level control
(control disc) and at the holder (see
Chapter 3.9) and pull it out in
backward direction.
9 Remove the Bowden pull wire for
vertical shock absorber adjustment at
the vertical shock absorber and at the
holder (see Chapter 3.11) and pull it
out in backward direction.
3
12
11
F
3
1
2
5
5
4
9
10
7
6
7
4
6
F
3
2
4
8
2
1
7
7
