Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.44 Seat suspension – removal and installation
Page 5 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
13 Detach the belt roller at the support
(upper suspension part) (see
Chapter 3.26), lead it upwards at the
webbing and secure it.
14 Remove the air hose for lumbar
support and lateral support
adjustment at the valve unit (see
Chapter 3.23).
15 Detach the cable of the heater
switch at the clip (see Chapter 3.20).
16 Detach the air hose for lumbar
support and lateral support
adjustment at the clip (see
Chapter 3.22).
3
12
11
F
3
1
2
5
5
4
9
10
7
6
7
4
6
F
3
2
4
8
2
1
7
7
