Grammer MSG 90.6PG - Page 373

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.47.1 Swivel and linkage rod – removal and installation
Page 2 of 4
REMOVAL / INSTALLATION TABLE OF CONTENTS
1 Position the backrest vertically and put
the seat onto the backrest.
2 Remove the supporting structure
(Chapter 3.39).
3 Remove the seat fore/aft adjustment
(Chapter 3.40).
