Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.51 Cable harness for vehicle connection – removal and installation
(seat with climate control system)
Page 7 of 8
REMOVAL / INSTALLATION TABLE OF CONTENTS
12 Mark the points where the cable for
the belt buckle contact (5) is
fastened to the seat support (13)
with two cable ties (15) and remove
the cable ties (15).
Installation note:
The cable for the belt buckle contact
(5) is placed in the bottom seam
(arrow) of the seat support (13).
13 Disconnect electrical connection (O).
14 Mark the point where the cable
harness of the vehicle connection (1)
is fastened to the level control (19)
with the cable tie (18) and remove
the cable tie (18).
9
8
7
A
O
K
5
1
1
2
3
F
417
L
6
19
18
1
1
11
10
15
5
5
15
13
4
2
17
6
16
14
F
L
2548
F
5
12
L
K
1
8
3
10
13
12
17
12
4
5
7
4
O
11
2
