Grammer MSG 90.6PG - 3.53 Control module for climate control system - removal and installation (seat with climate control system)

Repair Manual MSG 90.6PG Commercial Vehicles, Omnibuses – November 2017
Material no. 1153450_c
3.53 Control module for climate control system – removal and installation
(seat with climate control system)
Page 1 of 3
REMOVAL / INSTALLATION TABLE OF CONTENTS
(1) Control module for the climate
system
(2) Backrest frame
(3) Blind rivet
(4) Cable harness for backrest
(5) Bracket (at the connector)
(6) Catcher (at the connector)
(7) Connector
