Grandaire WFAR060B048C - Page 22

22 440 04 7113 02
Specifications subject to change without notice.
Burner Flame
Burner
Manifold
A11461
Fig. 12 -- Burner Flame
SET SCREW
MOTOR WHEEL HUB
MOTOR SHAFT FLAT
SCREW
MOTOR ARM
GROMMET
SCREW LOCATION
BLO HSG ASSY
BRACKET
BRACKET
ENGAGEMENT
SEE DETAIL
A
CAPACITOR
OR POWER CHOKE
(WHEN USED)
BRACKET
SCREW
(GND)
BLOWER HSG ASSY
MOTOR, BLOWER
WHEEL, BLOWER
CUTOFF, BLOWER
DETAIL A
A11584
Fig. 13 -- Blower Assembly
