Figure 14: MPK page
In this section, The MPKs are listed by order (From 1 to 10). Users can configure an MPK by choosing the Mode they need to
set (Speed dial, Busy Lamp Field…) and then set the Value for the MPK and its Label (Description of the button). When done,
scroll down and press on Save to save the configuration.
The Preview section will show the label of each configured MPK in order:
Figure 15: MPK Preview
Users can print the card containing the configured MPK information by pressing on Print and then configure the printing
options and preferences such as the Print Destination, print all pages or specific ones, Layout, Paper size, Margins, Scale,
whether to display headers and footers and background colors …
Note:
Multicast paging can be configured on the MPKs for GRP2604P phones.
