Grandstream Networks GXP2135

Wall Mount Yes 1
Quick Start Guide Yes 1
Table 8: GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 Equipment Packaging
Connecting Your Phone
Handset Port RJ9 handset connector port
Headset Port RJ9 headset connector port (supporting EHS with Plantronics headset)
USB Port
USB port connecting a USB flash drive. (only on
GXP2140/GXP2160/GXP2170)
LAN Port 10/100/1000Mbps RJ-45 port connecting to Ethernet
PC Port 10/100/1000Mbps RJ-45 port connecting to PC
EXT Port
RJ11 connector port to connect the GXP2200EXT Board (only on
GXP2140/GXP2170)
Power Jack 12V DC Power connector port
Table 9: GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 Connectors
To set up the GXP2130/GXP2140/GXP2160/GXP2170/GXP2135, follow the steps below:
